Actual site photos
The Appendix D site photos brought into the workspace as real visual evidence, not just text summary.
Appendix D extracted images
These are the actual site-photo images extracted from Appendix D - Site Photos - 02 June 2026 and resized for GitHub Pages. They are included as working visual context for the site visit, concept discussion and tender questions.
The source PDF is also downloadable from the document register. This page gives the team the practical visual evidence without asking everyone to dig through the PDF pack.
Actual tender-pack imageryWorking evidenceNot design recommendation
Full photo set
What to check on site
- Whether the visible water pooling is drainage design, maintenance, recent rain, low spots or a mix.
- Which surface cracks and joints match the Appendix C priority repair thresholds.
- Whether debris and organic build-up are isolated maintenance issues or signal ongoing water/shelter/vegetation interactions.
- How the shelter, fencing, seating and surrounding trees affect access, staging, safety and user experience.
- Which conditions need survey, levels, service locating, structural review or RPEQ input before drawings get serious.
